| Dimension | 164-80x100x2-8mm-1690218 |
|---|---|
| Touch panel | Capacitive |
| Dimensions with touch panel | 164.9 x 100 x 4.67mm |
| Screen diagonal | 7.0 |
| Resolution | 1024x600px |
| Brightness | 220cd-m%c2%b2-2-1690254 |
| Viewing angles | 80 ° / 80 ° / 80 ° / 80 ° |
| Orientation | Full |
| Matrix type | IPS |
| Communication interface | LVDS |
| Supply voltage | 3.3V |
| Display driver | HX8696A |
| Touch panel driver | FT5426 |
| The color of the touch panel | Black |
| Has PCB | Not |
| Tape assembly | To the FPC connector |
| Working temperature | -20 ÷ 70 ° C |
| Storage temperature | -30 ÷ 80 ° C |
